5T/H All In One Mango Juice Processing Machine 200KW Fruit Wash Machine
Product Details:
| Place of Origin: | Shanghai |
| Brand Name: | Gofun |
| Model Number: | GFM-MPL |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | International standard package for shipping |
| Delivery Time: | 45~90 days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 100 sets per year |
|
Detail Information |
|||
| Certification: | CE ISO | Voltage: | 220V/380V |
|---|---|---|---|
| Power(w): | 200KW | Condition: | New |
| Capacity: | Up To The Customer | Application: | Mango |
| Function: | Fruit Wash Machine | After-sales Service: | Online Support |
| High Light: | 5T/H Mango Juice Processing Machine,Mango Juice Processing Machine 200KW,All In One Mango Processing Line |
||
Product Description
5T/H high quality all in one service mango juice processing machine good after service
Product description of the mango processing line
The processing line mainly includes fresh mango receiving system, washing system, sorting system, destoning removing system, pre-heating system, pulping and refining system, filtration system, concentrating system, sterilizing system, and aseptic filling system. Then we can get the final products with the aseptic bag in drum.
Mango processing line can produce from fresh mango to different kinds of the final product. The popular products like mango pulp, mango puree, mango concentrate paste, mango sauce, mango juice, mango beverage processing line, which produce from fresh mango to the final product with the aseptic bag in drum.
Gofun can not only provide the tomato processing equipment for the plant but also provide the one-stop solution from A to Z, which includes:
- Technical consultation
- Customized proposal design
- Equipment manufacturing
- Installation commissioning and training at the site
- 1- year after-sales guarantee
- Life-long service
- Package design & Purchasing
Main parameters of the mango production line
| Product name: | One-stop solution for mango processing line |
| Fresh fruit inlet capacity: | 500kg per hour ~ 25 tons per hour, customized |
| Raw material: | Fresh mango |
| End product: | Mango pulp puree, Mango concentrate, Mango sauce, Mango juice, Mango beverage |
| Final product Brix: | 14%~20% |
| Final package: | Aseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc |
| The main material for machines: | Food grade SUS304 or SUS316 |
| Warranty: | 12 months after commissioning |
| Operator needed: | About 10~12 persons |
| Voltage: | 380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard) |
| Advantages: | Energy-saving, High efficiency, Water-saving, Stable performance |
Flowchart of tomato paste/ sauce or ketchup processing
Final products & Package types for the mango project
For final package, it can be aseptic bag, metal can, sachet, stand-up pouch, PP container, glass bottle, PET bottle, gable top, etc.
Key process of the mango processing line
Now Shanghai Gofun machinery company will introduce the information of mango pulp puree or mango paste concentrate processing line to show it works.
1. Elevator
This machine is used to deliver fresh mango from outside the building to inside.
2. Washing
Before crushing, need to washing fresh fruit carefully. For washing, we can use the bubble washing machine and brush & spray washing machine together. If the washing requirement is high, more stages of washing can be added. Also, for a better cleaning effect, we can add ultrasonic cleaning and ozone cleaning.
3. Destoning
The mango destoner is running with speed of 1470 r/min to crush fresh mango to make sure all the mango cores and peals are fully cleaned, which can greatly reduce the waste and improve the pulp yield. The cores will be sent outside factory, and the pulp will be pumped to next step.
4. Preheating
The pre-heater is used to heat the product after crusher, the temperature is adjustable, normally from 45℃ to 85℃. This processing step, would help to higher the juice rate for next step, and also can protect the color and taste of the final product.
5. Horizontal spiral centrifugal
The machine is used to reduce solids and impurities and ensure the mango pulp puree no impurities and black points.
6. Sterilizing
This way also can protect the test and nutrients of tomato paste as much as possible. The whole system adopts programmable control. The operating system adopts the image man-machine interface, which is convenient for intuitively grasping the operating status of each component of the device.
7. Aseptic Filling
CIP and auto SIP available together with sterilizer. Easy to adjust to match the different volumes and sizes of aseptic bags
8. Storage or go blending
The finished product can be stored or used as the raw material to make the tomato sauce or ketchup.
9. Mixing and blending
The tomato paste or fruit concentrate in the aseptic bag in drum can be taken out during the dry season for repacking to ensure continuous production.
10. Degassing & Homogenizing
Degassing machine is used to remove the bubbles and airs in the fruit pulp or mixed product. Homogenizer in food processing means to refine the material under the triple action of extrusion, strong impact and pressure loss expansion, so that the materials can be mixed with each other more evenly.
11. Pasteurizing
Kill the bacterial of the mixed product and improve the shelf-life.
12. Different packages filling system
For weighing, filling, sealing of the final package.
13. Water Spray or Immersion Pasteurizing and Cooling
It is the ideal equipment for materials to achieve the purpose of extending shelf life through sterilization, heat preservation and cooling, especially the secondary sterilization equipment necessary for automated production lines.
14. Air drying
Dry the metal can or sachet bag after the pasteurization.
15. Power Station of the whole plant
The system includes steam supply, compressed air supply, cooling water supply, ice water supply, power supply and so on.
Main equipment: steam boiler, water cooling tower, air compressor, RO water treatment, ice water machine, etc.
Main features of the tomato processing line
The Mango processing line is the key product of Shanghai Gofun machinery company. We served more than 20 countries in the past 16 years. We keep providing high-quality machines and services to food manufacturers all over the world.
1. The capacity of fresh fruit can be customized from 60 Tons/ Day to 1500 Tons/Day.
2. The Brix of final tomato paste can be designed as the customer’s requirement.
3. The final mango paste will be filled into aseptic bags in drum. With this kind of package, the shelf time can reach two years in normal temperature. Which can reduce the expense greatly for transportation and storage.
4. All the materials are food standard, the main material is SUS304 or SUS316, which fully meets the requirements of food hygiene and safety.
5. Besides aseptic bag filling, we can also provide metal can, small sachet, stand-up pouch, glass jar, PET/PP container, etc.
6. Key points of the production line adopt international first brand. (Steam valve adopts Spirax Sarco, Siemens PLC etc.)
After-Sales Service
1. Oversea technical support
2. Oversea equipment maintenance
3. English speaking engineers available to provide technical support
Working video of our mango pulp production line
