Strawberry Blueberry Berry Processing Equipment / Juice Production Machine

Place of Origin Shanghai, China
Brand Name Gofun
Certification CE, ISO certificate
Model Number GFM-BPL
Minimum Order Quantity 1 set
Price Negotiable
Payment Terms T/T, L/C, Western Union
Supply Ability 30 sets per year
Product Details
Voltage 220/380/440V, According To Customers Certificate CE/ISO9001
Type Turnkey Solution, Whole Processing Line Material SUS 304, 316, Accourding To Customer
Capacity 20T/day ~ 1500T/day, According To Customers Application Strawberry, Raspberry, Blueberry, Mulberry, Wolfberry, Etc.
Product Name Berry Processing / Making Machine / Production Line End Products Pulper, Paste, Puree, Jam, Juice, Beverage, Dried Fruit
After-sales Service Engineers Available To Service Overseas
High Light

blueberry processing plant

,

jam processing machine

Leave a Message
Product Description

Strawberry blueberry raspberry pulp paste processing puree jam production machine



Description



Gofun’s berry processing line is suitable for blueberries, blackberries, raspberries, strawberries and so on, which is used to generate fruit pulper, puree, paste, clear juice, cloudy juice, concentrated juice, jam and other end products.This production line is mainly composed of Fruit Washing Machine, Sorting Machine, Destoner, Fruit Crusher, Fruit Pulper and Refiner, Evaporation System, Sterilizer and Aseptic Filling System.



The highly automated berry processing line is designed with advanced design concepts. The main equipment is made of high quality food grade stainless steel, which is in accordance with the hygienic requirements of food processing.



Raw material

Blueberry, blackberry, raspberry, strawberry, etc.

End product Pulp, paste, puree, jam, juice, beverage, dried berry
Processing capacity From 20 T/day to 1500 T/day
Juice yield 85% raw fruit (15% as waste, peels and seeds)
End package Aseptic bag, metal can, glass bottle, PET bottle, etc.





Features



1. Widely usage range and easy to maintain
2. Advanced design, steel structure, strong and beautiful
3. Low measurement error, high sensitivity, stable and reliable
4. Low Power consumption, low noise and easy to operate
5. The sorting grade can be adjusted, high efficiency, high output
6. Automatic protection function, prevent reversal and error operation damage to equipment
7. Advanced preliminary array technology, labor-saving.
8. Durable and well design fruit plate, no damage to the fruit, cost saving.

9. The machine is made of 304 stainless steel. It has the advantages of beautiful appearance, easy installation, convenient operation, environment protection, sanitation, safety, reliability and efficiency production.



Advantages



1. High degree of automation: to minimize the number of operators on the production line.
2. International First-Class brands electrical components: to ensure the stability and reliability of equipment operation;
3. Human-machine interface operation: to display the operation and state of the equipment on the touch screen in the process of production,
4. Linkage control: to automatically and intelligently respond to possible emergencies.



Flowchart



Strawberry Blueberry  Berry Processing Equipment / Juice Production Machine 0



Berry Paste/Pulp/Jam Processing Line

FRESH BERRY ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ CRUSHING ⇒ PREHEATING ⇒ PULPER & REFINER ⇒ EVAPORATING ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING



Related Machine



Strawberry Blueberry  Berry Processing Equipment / Juice Production Machine 1

Strawberry Blueberry  Berry Processing Equipment / Juice Production Machine 2

Strawberry Blueberry  Berry Processing Equipment / Juice Production Machine 3



Company Information



Shanghai Gofun machinery company, a professional fruit and vegetable processing line manufacturer and exporter in China. Which can offer the turn-key solution for different fruits juice, pulp & paste processing complete line with high quality and competitive production lines with daily capacity from 60 tons to 1500 tons and customizations including plant construction, equipment manufacturing, installation, commissioning and production; provide the most optimized implementation plan.Gofun Company provides the turn-key solution for not only the tomato paste production line but also the processing lines for many kinds of fruits & vegetables, like apples, pears, plums, coconuts, mulberries, ect., and has received widespread praises from customers from both the domestic and overseas. Our machines have already been exported to all over the world including the Asian countries, African countries, South American countries and even European countries.



Our Services



1. Technical support

2. Marketing suggestion

3. Final packing suggestion and design

4. Factory building and design





After-Sales Service



1. Comprehensive engineering services

2. Installation supervision

3. Commissioning support

4. Operator training
