Low-Temperature Dehumidifying for Fruit Drying Machines

Low-Temperature Dehumidifying for Fruit Drying Machines

Place of Origin Shanghai, China
Brand Name Gofun
Certification CE, ISO
Model Number GFM-CD-15
Product Details
Warranty:
1 Year
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Voltage:
220/380/440V, According To Customers
Certification:
CE/ISO9001
Type:
Dryer
Material:
Food Standard SUS 304, 316, Accourding To Customer
Capacity:
5-1000kg/hour According To Customers
Application:
Agricultural And Sideline Products, Seafood, Fruits And Vegetables, Dried Fruits
Product Name:
Heat Pump Low Temperature Dehumidifier
End Products:
Agricultural And Sideline Products, Seafood, Dried Fruits, Etc.
Special Process:
Integrated Structural Design,With High Temperature Hot Air Circulation Drying
Highlight:

low-temperature fruit drying machine

,

dehumidifying fruit dryer

,

fruit drying machine with dehumidifier

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiable
Packaging Details
International standard packaging for shipping
Payment Terms
T/T,Western Union,L/C,Visa
Supply Ability
20 sets per year
Product Description
Low-Temperature Dehumidifying for Fruit Drying Machines
Our advanced fruit drying machines utilize high-performance heat pump low-temperature dehumidifier technology, engineered with sophisticated low dew point dehumidification that simulates natural dry winter conditions. This innovative system creates a gentle, stable drying environment with precise temperature and humidity control, eliminating risks of overheating, discoloration, or flavor loss common in conventional drying equipment.
Unlike traditional high-temperature methods that damage texture and nutritional value, our system optimally preserves the original shape, vibrant color, and authentic fresh flavor of fruits throughout the entire drying process. Ideal for berries to tropical varieties, these machines deliver consistent, high-quality dried products while maximizing energy efficiency and reducing operational costs for food processing enterprises.
Working Principle
  • Moist, hot air is drawn into the system through negative-pressure circulation fan
  • Air undergoes three-stage cooling and dehumidification process
  • Condensed moisture is efficiently drained away
  • Transformed into low-temperature, low-humidity drying air
  • Heat exchange warms the air while further reducing humidity
  • Conditioned air is distributed back into the drying chamber
Low-Temperature Dehumidifying for Fruit Drying Machines 0
Low-Temperature Dehumidifying for Fruit Drying Machines 1
Material Applications
Ideal for drying and extracting cell liquid from various materials including:
  • Roses, chrysanthemums, honeysuckle
  • Gardenia, jasmine, American ginseng
  • Cistanche and other Chinese herbal medicines
  • Aquatic products and heat-sensitive fruits
Low-Temperature Dehumidifying for Fruit Drying Machines 2
Technical Advantages
  • Precise temperature control: 15-30°C adjustable range
  • Accurate humidity control: 5-99% RH adjustable
  • Efficient dehumidification: Average 22KG/hour at 25°C and 70% RH
  • Automatic adjustment: Fan air pressure and speed adapt to conditions
  • Negative pressure cold-air circulation: Ensures excellent drying uniformity
  • Closed system: Maintains stable quality with energy-efficient operation
Technical Specifications
Unit Model Compressor Power Power Input (KW) Heating Power (KW) Rated Temperature Rated Voltage (V) Rated Current (A) Environmental Temperature(℃) Working Fluid Charge(KGS) Sound Level (DB) Machine Size W*L*H(MM) Weight (KG)
GFM-CD-15 6HP 4.5 15 28/30 380 8.6 5-45 4.5 55 1800x1650x1754 450
GFM-CD-30 12HP 9 30 28/30 380 17.2 5-45 9 55 1800x1650x1754 600
Heat Pump System Principle
The high temperature heat pump consists of compressor, condenser, throttling device and evaporator. The refrigerant cycle efficiently transfers low temperature heat to high temperature medium.
Low-Temperature Dehumidifying for Fruit Drying Machines 3
Low-Temperature Dehumidifying for Fruit Drying Machines 4
Process Display
Low-Temperature Dehumidifying for Fruit Drying Machines 5
Low-Temperature Dehumidifying for Fruit Drying Machines 6
Low-Temperature Dehumidifying for Fruit Drying Machines 7
Low-Temperature Dehumidifying for Fruit Drying Machines 8
Low-Temperature Dehumidifying for Fruit Drying Machines 9
Low-Temperature Dehumidifying for Fruit Drying Machines 10
Company Information
Gofun Company offers comprehensive turnkey solutions for fruit processing and packaging lines. Our machines have been successfully exported worldwide to Asia, Africa, South America, Europe, and North America.
Low-Temperature Dehumidifying for Fruit Drying Machines 11
Low-Temperature Dehumidifying for Fruit Drying Machines 12
Low-Temperature Dehumidifying for Fruit Drying Machines 13
Low-Temperature Dehumidifying for Fruit Drying Machines 14
Our Services
  • Technical support
  • Marketing suggestions
  • Final packing suggestion and design
  • Factory building and design
  • Oversea technical support
  • Oversea equipment maintenance
  • English speaking engineers available
