Automatic Fruit Processing Line Mango Paste Processing Line Energy Saving
  • Automatic Fruit Processing Line Mango Paste Processing Line Energy Saving

Automatic Fruit Processing Line Mango Paste Processing Line Energy Saving

Place of Origin Shanghai
Brand Name Gofun
Certification CE, ISO
Model Number GFM-MPL
Product Details
Warranty:
12 Months
After-sales Service Provided:
Worker Training
Voltage:
220V, According To Customers
Type:
Complete Mango Paste Processing Line
Material:
Stainless Steel 304 / 316
Capacity:
60 Tons / Day, Can Be Customized
Application:
Food & Beverage Factory, Farms
Product Name:
Mango Paste Processing Line
Package:
Aseptic Bag
Highlight:

fruit juice production line

,

fruit juice processing equipment

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiable
Payment Terms
T/T, Western Union, L/C
Supply Ability
20 sets per year
Product Description

High quality Mango Paste Processing Line Energy Saving Safety Control For Operators



Description



  1. Capacity of fresh mango can be customized from 60 Ton/D to 1500Ton/D.
  2. Birx of mango paste can be designed as customer’s requirement.
  3. Final mango paste / juice will be filled into aseptic bags in drum. With this kind of package, the shelf time can reach two years in normal temperature.
  4. All the materials are food standard, the main material is SUS 304 or SUS316. Depends on the requirements.
  5. Beside aseptic bag filling, we also can provide metal can, small sachet, stand-up pouch, PET/PP container, etc.
  6. Waste fruit or vegetable from production line can be produced into fertilizer.



Aapplication



Mango processing line can produce from fresh mango to different kinds of final product. For example, mango juice, mango paste, mango pulp, dried mango. And the mango product is getting more and more popular in Chinese market. To reach the increasing requirement of mango product, Shanghai Gofun machinery company has created a mango processing segment that provides all of the necessary mango processing machinery for all kinds of mango product. For example, mango concentrate juice, mango juice, mango puree, dried mango, etc.



Raw material Fresh mango
End product Concentrated juice, clear juice
Processing capacity From 60 tons/day to 2000 tons/day
Efficient input 75% raw fruit (25% as waste,peels and seeds)
Fruit consistence 10-12Brix
Product consistence 70~72Brix for concentrated juice
End package Aseptic bag/tin can/glass bottle/PET bottle
Output Can be calculated



Flowchart



Automatic Fruit Processing Line Mango Paste Processing Line Energy Saving 0



Mango Paste/Puree Processing Line



1. FRESH MANGO

2. CONVEYOR

3. WASHING

4. SORTING

5. DESTONING

6. PREHEATING

7. PULPER & REFINER

8. EVAPORATING

9. STERILIZING

10. ASEPTIC FILLING

11. STORAGE OR BLENDING



Our Services



SPARE PARTS

For providing the high level of efficiency to the Customer, we take care with particular attention that our stores are always best furnished, in order to perform the deliveries in the shorter time which is possible for reducing the incidental stops of the plants at the minimum level.

ON SITE ASSISTANCE

Further important investments have been allocated for improving the assistance methods on site, guaranteeing well-timed interventions on the markets in which the installed machinery and the service volume require presence and availability. You can consider your machines' maintenance and performance in good hands.

TRAINING

New resources have been dedicated to improve the theoretical education of the Customer’s employees, concerning the training about production line, supervision and production assistance.



Company Information



Shanghai Gofun Machinery Company is an incorporated company with strong technical research and development capabilities of new products. Through integration of absorbing advanced mechanical design and automation control technology from Europe and America, Gofun Company has achieved a comprehensive technology upgrade in the processing technology and equipment improvements for fruit juice, puree, paste, dried fruits, juice drinks and etc.



We design and manufacture the whole fruit and vegetable processing and packaging line. We provide the best solution and the most optimal designs according to the customer’s exact situation and requests. Manufacturing quality equipment is our basic duty, focusing on customers’ every need and providing the most optimal solution is the value we represent.



Gofun Company provides the turn-key solution for not only the tomato paste production line but also the processing and packaging lines for apple, pear, peach, mango, and apricot and other fruits & vegetables, and has received wide spread praises from customers in both the domestic and overseas markets. The machines have already been exported to all over the world including the Asian countries, African countries, South American countries and even European and American countries.



Gofun Company aim to create the outstanding food machinery and contribute to the world's agricultural industry. We sincerely committed ourselves to a brilliant prospect and mutual benefit relationship with all of the people and friends from Worldwide!



Automatic Fruit Processing Line Mango Paste Processing Line Energy Saving 1
