380V 50Hz 500T/D Mango Jam Processing Line For Food Industry

380V 50Hz 500T/D Mango Jam Processing Line For Food Industry

Product Details:

Place of Origin: Shanghai
Brand Name: Gofun
Certification: CE, ISO certificate
Model Number: GFM-MPL

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: International standard package for shipping
Delivery Time: 45~90 days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 100 sets per year
Get Best Price Contact Now

Detail Information

Warranty: 1 Year Capacity: 500T/D
Application: Mango Name: Mango Jam Processing Machines
Dimension(l*w*h): According To The Capacity Product Name: Fresh Fruits Making Machine
High Light:

500T/D Mango Jam Production Line


Food Industry Mango Jam Processing Line


380V 50Hz Mango Processing Line

Product Description

500T/D Industrial High Quality Mango Jam Processing Line Good After Service
Product description of the mango processing line
The processing line mainly includes fresh mango receiving system, washing system, sorting system, destoning removing system, pre-heating system, pulping and refining system, filtration system, concentrating system, sterilizing system, and aseptic filling system. Then we can get the final products with the aseptic bag in drum.
Mango processing line can produce from fresh mango to different kinds of the final product. The popular products like mango pulp, mango puree, mango concentrate paste, mango sauce, mango juice, mango beverage processing line, which produce from fresh mango to the final product with the aseptic bag in drum.
Gofun can not only provide the tomato processing equipment for the plant but also provide the one-stop solution from A to Z, which includes:

  • Package design & Purchasing
  • Customized proposal design
  • Equipment manufacturing
  • 1- year after-sales guarantee
  • Life-long service
  • Technical consultation
  • Installation commissioning and training at the site


Main parameters of the mango production line

Product name:One-stop solution for mango processing line
Fresh fruit inlet capacity:500kg per hour ~ 25 tons per hour, customized
Raw material:Fresh mango
End product:Mango pulp puree, Mango concentrate, Mango sauce, Mango juice, Mango beverage
Final product Brix:14%~20%
Final package:Aseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
The main material for machines:Food grade SUS304 or SUS316
Warranty:12 months after commissioning
Operator needed:About 10~12 persons
Voltage:380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Advantages:Energy-saving, High efficiency, Water-saving, Stable performance

Flowchart of tomato paste/ sauce or ketchup processing



380V 50Hz 500T/D Mango Jam Processing Line For Food Industry 0


Final products & Package types for the mango project
Shanghai Gofun machinery company offers all kinds of mango processing line.
The raw material can be fresh mango, mango paste, etc. And the final product can be mango paste, mango sauce, mango juice, mango powder, diced mango, dried mango, etc.

380V 50Hz 500T/D Mango Jam Processing Line For Food Industry 1
For final package, it can be aseptic bag, metal can, sachet, stand-up pouch, PP container, glass bottle, PET bottle, gable top, etc.


380V 50Hz 500T/D Mango Jam Processing Line For Food Industry 2
Main features of the tomato processing line
The Mango processing line is the key product of Shanghai Gofun machinery company. We served more than 20 countries in the past 16 years. We keep providing high-quality machines and services to food manufacturers all over the world.

1. The capacity of fresh fruit can be customized from 60 Tons/ Day to 1500 Tons/Day.

2. Besides aseptic bag filling, we can also provide metal can, small sachet, stand-up pouch, glass jar, PET/PP container, etc.

3. The operation is simple and humanized. All feeding and maintenance areas are designed with feeding and maintenance platforms, to ensure the security of the operators.

4. All the materials are food standard, the main material is SUS304 or SUS316, which fully meets the requirements of food hygiene and safety.

5. The Brix of final tomato paste can be designed as the customer’s requirement.

6. Key points of the production line adopt international first brand. (Steam valve adopts Spirax Sarco, Siemens PLC etc.)

7. The whole production line design is compact and scientific, stable operation, high efficiency and energy saving, low steam consumption.

8.The final mango paste will be filled into aseptic bags in drum. With this kind of package, the shelf time can reach two years in normal temperature. Which can reduce the expense greatly for transportation and storage.

9. We can also design the customized processing line for different types of fruit and vegetable. It can produce clear juice, turbid juice, original pulp, concentrated juice, concentrated pulp, fruit powder, jam, vinegar, wine, and other products.

10. The waste from the production line can be produced into fertilizer.
