Product Details:

Place of Origin: Shanghai
Brand Name: Gofun
Certification: CE, ISO 9001
Model Number: GFM-TS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Delivery Time: 60 days
Payment Terms: T/T
Supply Ability: 30 sets per year
Get Best Price Contact Now

Detail Information

Material: 304/316 Stainless Steel Application: Fruit Sterilizing
Warranty: 12 Months Cleaning: CIP Cleaning System Available
Power: 15kw Capacity: 0.5-5 Tons/ Hour, Customized
Function: Sterilization Usage: Fruit Processing Plant
After-sales Service Provided: Engineers Available To Service Machinery Overseas Advantage: High Efficiency,Energy Saving,competitive Price,Easy Operation
High Light:

Eco Friendly UHT Sterilizer Machine


Complete Processing UHT Sterilizer Machine


15kw Pasteurizing UHT Sterilizer Machine

Product Description

Eco-friendly Pasteurizer for fruit products complete processing line low consumption




Shanghai Gofun machinery company offers all kinds of sterilization processing line. The sterilization way can be tubular type sterilizer, tube in tube type sterilizer or others.


The capacity of fruit and vegetable sterilizer processing line is varied from 20 T/day to 1500 T/day. The line can also be shared for processing other fruits with similar characteristics. The whole sterilization last only 30 seconds, which allows to maintain products freshness. The sterilization rate is especially no less than 75%. The end products are of good taste and nice color. Multi-effect evaporator can be chosen for different capacity. Either fully automatic line or semi-automatic line can be chosen according to the cost.




The sterilizing temperature and holding time is adjustable. With this machine, the fruit or vegetable juice/paste/pulper can be heated to a very high temperature around 115℃, held for 30s and then cooled to ambient temperature immediately. UHT sterilizer can protect the taste and nutrients of fruits or vegetables as much as possible.


Model GFM10D1000 GFM10D3000 GFM10D5000 GFM10D8000
capacity(L/H) 1000 3000 5000 8000
power(KW) 15 25 40 72
System design pressure(MPa) 4 5 10 16
Steam consumption(kg/h) 250 750 1300 2000
Compressed air consumption(m³/h) 12 12 12 12
Cooling water consumption(t/h) 15 25 45 70
Material sterilization temperature(℃) 90-125 90-125 90-125 90-125
Sterilization time(s) 120-180 120-180 120-180 120-180
Feed temperature(℃) 60-68 60-68 60-68 60-68
Discharge temperature(℃) ≤40 ≤40 ≤40 ≤40
Exterior dimension(mm) 9500X2100X3000 1100X2100X3000 1200X2400X3000 1300X2500X3000



- Main structure with SUS 304 stainless steel.

- Combined Italian technology and conform to Euro-standard.

- Great heat exchange area, low energy consumption and easy maintenance.

- Adopt mirror welding tech and keep the smooth pipe joint.

- Auto backtrack if not enough sterilization.

- All the junction and joint with steam protection.

- Liquid level and temp controlled on real time.

- Separate control panel, PLC and human machine interface.

- CIP and auto SIP available together with aseptic bag filler.


Competitive Advantages


1. High-tech enterprise with our own professionally team and manufactured factory.

2. Advanced technology at home and abroad leading level, and granted technology patents.

3. Location in national key high-tech zone, only 30mins to airport.

4. Strict quality inspection, all products are advanced and durable with high reputation.

5. Good pre-sales and after-sales service.


Company Information


Gofun is the professional manufacturer in China with 16 years experience. Our main business includes:


1st: Provide the separation equipment for fruit & vegetable, such as: washing/sorting/crushing/pulping & refining/ evaporating/ sterilizing/ filling/ packing/ pasteurizing/ HPP/, etc.

2nd: Provide whole plant of fruit processing, typically tomato processing plant, tropical fruit (mango/ pineapple/ guava/ passionflower/ papaya and etc.) processing plant, normal furit(strawberry/ apple/ pear/ peach/ apricot) processing plant.

3rd: Provide whole plant of filling line of all kinds of packages. Like aseptic bag, metal can, sachet, stand-up pouch, PP container, glass bottle, PET bottle, gable top, etc.
