Mechanized 3T/H Tomato Paste Processing Line With Washing Sorting
|Advantage||High Quality Service||Product Name||Tomato Paste Processing Line|
3T/H Tomato Paste Processing Line,
Mechanized Tomato Paste Processing Line,
SUS316 Sorting Tomato Paste Processing Line
Mechanized Production 3T/H Tomato Paste Processing Line High Quality Service
Product description of tomato processing plant
The processing line mainly includes: fresh tomato receiving system, washing system, sorting system, crushing system, pulping and refining system, filtration system, concentrating system, sterilizing system, and aseptic filling system. Then we can get the tomato paste with aseptic bag in drum.
Gofun can not only provide the tomato processing equipment for the plant but also provide the one-stop solution from A to Z, which includes:
- Technical consultation
- Customized proposal design
- Installation commissioning and training at the site
- Life-long service & 1- year after-sales guarantee
- Package design & Purchasing
Flowchart of tomato paste/ sauce or ketchup processing
FRESH TOMATO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ CRUSHING ⇒ PREHEATING ⇒ PULPER & REFINER ⇒ EVAPORATING ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING
Main parameters of tomato production line
|Product name:||One-stop solution for tomato processing line|
|Fresh fruit input capacity:||500kg per hour ~ 25 tons per hour|
|Raw material:||Fresh tomato, tomato paste|
|End product:||Tomato paste, tomato sauce or ketchup, tomato juice, etc|
|Final product Brix:||28%~30%, 36%~38%|
|Final package:||Aseptic bag, Metal can, Sachet, Stand-up pouch, PP container, Plastic bottle, Glass jar, etc|
|The main material for machines:||Food grade SUS304 or SUS316|
|Warranty:||12 months after commissioning|
|Operator needed:||About 10~12 persons|
|Voltage:||380V 50Hz/ 110V 60Hz/ 415V 50Hz|
|(adjustable to client's country standard)|
|Advantages:||Energy-saving, high efficiency, water-saving
Final products & Package types for tomato project
Shanghai Gofun machinery company offers all kinds of the tomato processing line.
The raw material can be fresh tomato, tomato paste, etc. And the final product can be tomato paste, tomato ketchup, tomato sauce, tomato juice, tomato powder, whole peeled tomato, etc.
Main features of the tomato processing line
The tomato processing line is the key product of Shanghai Gofun machinery company. We served more than 20 countries in the past 16 years. We keep providing high-quality machines and services to food manufacturers all over the world.
1. The capacity of fresh fruit can be customized from 60 Tons/ Day to 1500 Tons/Day.
2. The tomato can be hot crushed or cold crushed.
3. The Brix of final tomato paste can be designed as the customer’s requirement, normally it would be 28-30% or 36-38%.
4. The final tomato paste will be filled into aseptic bags in drum. With this kind of package, the shelf time can reach two years at normal temperature. Which can reduce the expense greatly for transportation and storage.
5. All the materials are food standard, the main material is SUS304 or SUS316, which fully meets the requirements of food hygiene and safety.
6. Besides aseptic bag filling, we can also provide metal can, small sachet, stand-up pouch, glass jar, PET/PP container, etc.
7. Key points of the production line adopt the international first brand. (Steam valve adopts Spirax Sarco, Siemens PLC etc.)
8. The whole production line design is compact and scientific, stable operation, high efficiency and energy-saving, low steam consumption;
9. The operation is simple and humanized. All feeding and maintenance areas are designed with feeding and maintenance platforms, to ensure the security of the operators.
10. We can also design a customized processing line for different types of fruit and vegetable. It can produce clear juice, turbid juice, original pulp, concentrated juice, concentrated pulp, fruit powder, jam, vinegar, wine, and other products.
11. The waste from the production line can be produced into fertilizer.
Key process of the tomato paste processing line
Now Shanghai Gofun machinery company will introduce the information of tomato paste processing line to show it works.
This machine is used to delivery fresh fruit from outside the building to inside.
Before crushing, need to washing fresh fruit carefully. For washing we can use bubble washing machine and spray washing machine together. If the washing requirement is high, more stages of washing can be added. Also, for better cleaning effect, we can add ultrasonic cleaning and ozone cleaning.
After washing, the surface of the fruit is clean, we can check the situation of all the fruit by human eye, and sort out the bad tomatoes by human.
4. Crushing for tomato processing
GFM-FC series crusher has most advanced working principle, higher accuracy of manufacture and best crushing functions. It is mainly used for crushing of many kinds of fruits or vegetables, for example: tomato, apple, pear, strawberry, celery, etc. it can crush the raw materials into small particles, which could increase the working effect of next processing section. The machine is composed of feed hopper, side cover, frame, principal axis, bearing block, motor, motor structure, outlet hopper etc.
The pre-heater is used to heat the product after crusher, the temperature is adjustable, normally from 45℃ to 85℃. This processing step, would help to higher the juice rate for next step, and also can protect the color and taste of the final product.
6. Pulper and refiner
The double stage pulping machine for tomato pulp yield rate can reach 90%~95%.
Vacuum Evaporator is used for concentrating the tomato paste under vacuum and low temperature. Here we are using Forced Circulation Vacuum Evaporator.
The operating system adopts the image man-machine interface, which is convenient for intuitively grasping the operating status of each component of the device.
9. Aseptic Filling
Easy to adjust to match the different volumes and sizes of aseptic bags
10. Storage or go blending
The finished product can be stored or used as the raw material to make the tomato sauce or ketchup.
