Stainless Steel Tomato Paste Processing Line Concentrated Sauce 1500 T/D

Place of Origin Shanghai
Brand Name Gofun
Certification ISO, CE certification
Model Number GFM-TPL
Minimum Order Quantity 1 SET
Price Negotiable
Packaging Details International standard package for shipping
Delivery Time 90 days
Payment Terms T/T, L/C, Western Union
Supply Ability 20 sets per year
Product Details
Voltage 220V, 380V, Customized Type Complete, Automatic
Material 304 Stainless Steel Capacity 60 T/d, 150 T/d, 250 T/d, 1500 T/d, Customized
Function Tomato Paste Processing Usage Industrial Usage
Product Name Tomato Processing Line, Multi- Functional Warranty 1year After Installation And Commissioning
Feature Labor Saving, High Efficiency, PLC Control Name Multiple Function Fruit Processing Line
High Light

1500 T/D Tomato Paste Processing Line

,

Concentrated Sauce Electric Tomato Machine

,

Stainless Steel Tomato Sauce Processing Equipment

Leave a Message
Product Description

SUS304 Concentrated Sauce Tomato Paste Processing Line 1500T/D



Product description of tomato processing plant



The tomato processing line can produce from fresh tomatoes to various types of end products. Popular products such as tomato paste, tomato sauce and ketchup is a tomato juice processing line that produces from fresh tomatoes to finished product with an aseptic packaging in the drum.



The processing line mainly includes: fresh tomato receiving system, washing system, sorting system, crushing system, pulping and refining system, filtration system, concentration system, sterilization system and aseptic filling system. We can then put the tomato paste in the drum with the aseptic bag.



And the tomato paste in aseptic bag in drum can be further processed into tomato ketchup, sauces, juice and filled into sachet, stand-up pouch, metal can, PP container, bottle, gable and so on.



Gofun can not only supply the tomato processing equipment for the plant, but also offer the one-stop solution from A to Z, which includes:

  • Technical advice
  • Individual offer design
  • device manufacturing
  • Installation commissioning and on-site training
  • 1 year after-sales guarantee
  • Lifetime Service
  • Packaging design & purchasing



Main parameters of tomato production line



Product name: One-stop solution for tomato processing line
Fresh fruit input capacity: 500kg per hour ~ 25 tons per hour
Raw material: Fresh tomato, tomato paste
End product: Tomato paste, tomato sauce or ketchup, tomato juice, etc
Final product Brix: 28%~30%, 36%~38%
Final package: Aseptic bag, Metal can, Sachet, Stand-up pouch, PP container, Plastic bottle, Glass jar, etc
The main material for machines: Food grade SUS304 or SUS316
Warranty: 12 months after commissioning
Operator needed: About 10~12 persons
Voltage: 380V 50Hz/ 110V 60Hz/ 415V 50Hz
(adjustable to client's country standard)
Advantages: Energy-saving, high efficiency, water-saving

Flowchart of tomato paste/ sauce or ketchup processing



FRESH TOMATO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ CRUSHING ⇒ PREHEATING ⇒ PULPER & REFINER ⇒ EVAPORATING ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING



Stainless Steel Tomato Paste Processing Line Concentrated Sauce 1500 T/D 0



Final products & Package types for tomato project



Shanghai Gofun machinery company offers all kinds of the tomato processing line.



The raw material can be fresh tomato, tomato paste, etc. And the final product can be tomato paste, tomato ketchup, tomato sauce, tomato juice, tomato powder, whole peeled tomatoes, etc.

Stainless Steel Tomato Paste Processing Line Concentrated Sauce 1500 T/D 1Stainless Steel Tomato Paste Processing Line Concentrated Sauce 1500 T/D 2

For final packaging it can be aseptic bag, metal can, sachet, base bag, PP container, glass bottle, pet bottle, pediment, etc.

Stainless Steel Tomato Paste Processing Line Concentrated Sauce 1500 T/D 3



Main features of the tomato processing line



The tomato processing line is the key product of Shanghai Gofun Machinery Company. We have served over 20 countries over the past 16 years. We continue to provide high quality machinery and service to food manufacturers around the world.



1. Fresh fruit capacity can be customized from 60 tons/day to 1500 tons/day.

2. The tomato can be crushed hot or cold.

3. Brix of final tomato paste can be designed according to customer's requirements, normally it would be 28-30% or 36-38%.

4. The final tomato paste will be filled into aseptic bags in a drum. With this type of packaging, the shelf life can reach two years at normal temperature. Which can greatly reduce transportation and storage expenses.

5. All materials comply with food standards, the main material is SUS304 or SUS316, which fully meets food hygiene and safety requirements.

6. In addition to aseptic bag filling, we can also provide canisters, small pouches, stand-up pouches, glass jars, PET/PP containers, etc.

7. The key points of the production line adopt the international first brand. (The steam valve adopts Spirax Sarco, Siemens PLC, etc.)

8. The whole production line design is compact and scientific, stable operation, high efficiency and energy saving, low steam consumption;

9. The operation is simple and humanized. All feeding and maintenance areas are designed with feeding and maintenance platforms, to ensure the safety of operators.

10. We can also design customized processing line for different kinds of fruits and vegetables. It can produce clear juice, cloudy juice, original pulp, concentrated juice, concentrated pulp, fruit powder, jam, vinegar, wine and other products.

11. Waste from the production line can be turned into fertilizer.





Our Services for tomato processing plant



1. Technical support

2. Marketing suggestion

3. Final packing suggestion and design

4. Factory building and design



After-Sales Service



1. Oversea technical support

2. Oversea equipment maintenance

3. English speaking engineers available to provide technical support
