220V SUS304 Tomato Ketchup Processing Line Equipment Energy Saving

Place of Origin Shanghai
Brand Name Gofun
Certification ISO, CE certification
Model Number GFM-TPL
Minimum Order Quantity 1 SET
Price Negotiable
Packaging Details International standard package for shipping
Delivery Time 90 days
Payment Terms T/T, L/C, Western Union
Supply Ability 20 sets per year
Product Details
Voltage 220V/380V Type Production Line
After-sales Service Engineers Available To Service Machinery Overseas Material 304 Stainless Steel
Name Tomato Paste Processing Machine Function High Efficiency Drying
Feature High Efficiency Product Name Tomato Paste Processing Line
High Light

Energy Saving Tomato Ketchup Processing Line

,

220V Tomato Ketchup Processing Line

,

Food grade SUS304 Tomato Processing Line

Leave a Message
Product Description

Convenient After Care Service Tomato Ketchup Processing Equipment 5T/H



Product description of tomato processing plant



The tomato processing line can produce from fresh tomatoes to various types of final product. Popular products such as tomato paste, tomato sauce and ketchup are a tomato juice processing line that produce from fresh tomatoes to the final product with an aseptic package in the drum.



The processing line mainly includes: fresh tomato reception system, washing system, sorting system, crushing system, pulp and refining system, filtration system, concentration system, sterilization system and aseptic filling system. We can then get the tomato paste with the aseptic bag in the drum.



And the tomato paste in aseptic bag in drum can be further produced to tomato ketchup, sauces, juice and filled in sachet, stand-up pouch, metal can, PP container, bottle, gable top, etc.



Gofun can not only provide the tomato processing equipment for the plant but also provide the one-stop solution from A to Z, which includes:

  • Technical consultation
  • Customized proposal design
  • Equipment manufacturing
  • Installation commissioning and training at the site
  • 1- year after-sales guarantee
  • Life-long service
  • Package design & Purchasing



Main parameters of tomato production line



Product name: One-stop solution for tomato processing line
Fresh fruit input capacity: 500kg per hour ~ 25 tons per hour
Raw material: Fresh tomato, tomato paste
End product: Tomato paste, tomato sauce or ketchup, tomato juice, etc
Final product Brix: 28%~30%, 36%~38%
Final package: Aseptic bag, Metal can, Sachet, Stand-up pouch, PP container, Plastic bottle, Glass jar, etc
The main material for machines: Food grade SUS304 or SUS316
Warranty: 12 months after commissioning
Operator needed: About 10~12 persons
Voltage: 380V 50Hz/ 110V 60Hz/ 415V 50Hz
(adjustable to client's country standard)
Advantages: Energy-saving, high efficiency, water-saving

Flowchart of tomato paste/ sauce or ketchup processing



FRESH TOMATO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ CRUSHING ⇒ PREHEATING ⇒ PULPER & REFINER ⇒ EVAPORATING ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING



220V SUS304 Tomato Ketchup Processing Line Equipment Energy Saving 0



Final products & Package types for tomato project



Shanghai Gofun machinery company offers all kinds of the tomato processing line.



The raw material can be fresh tomato, tomato paste, etc. And the final product can be tomato paste, tomato ketchup, tomato sauce, tomato juice, tomato powder, whole peeled tomatoes, etc.

220V SUS304 Tomato Ketchup Processing Line Equipment Energy Saving 1220V SUS304 Tomato Ketchup Processing Line Equipment Energy Saving 2

For final packaging it can be aseptic bag, metal can, sachet, base bag, PP container, glass bottle, pet bottle, pediment, etc.

220V SUS304 Tomato Ketchup Processing Line Equipment Energy Saving 3



Main features of the tomato processing line



The tomato processing line is the key product of Shanghai Gofun Machinery Co., Ltd. Over the past 16 years, we have served over 20 countries. We continue to provide high quality equipment and services to food manufacturers around the world.



1. Fresh fruit production can range from 60 tons per day to 1500 tons per day.

2. Tomato can be chopped hot or cold.

3. The Brix of the final tomato paste can be designed according to customer requirements, usually 28-30% or 36-38%.

4. Ready tomato paste will be packaged in aseptic bags in the drum. With such packaging, the shelf life can reach two years at normal temperature. Which can greatly reduce transportation and storage costs.

5. All materials comply with food standard, the main material is SUS304 or SUS316, which fully meets the requirements of hygiene and food safety.

6. In addition to aseptic bag filling, we can also provide metal cans, small sachets, stand-up bags, glass jars, PET/PP containers, etc.

7. The key points of the production line adopt the first international brand. (The steam valve uses Spirax Sarco, Siemens PLC, etc.)

8. The design of the whole production line is compact and scientific, stable performance, high efficiency and energy saving, low steam consumption;

9. The operation is simple and humanized. All feeding and serving areas are equipped with feeding and serving platforms to ensure the safety of operators.

10. We can also design a customized processing line for different kinds of fruits and vegetables. It can produce clear juice, cloudy juice, original pulp, concentrated juice, concentrated pulp, fruit powder, jam, vinegar, wine and other products.

11. Waste from the production line can be recycled into fertilizer.



Our Services for tomato processing plant



1. Technical support

2. Marketing offer

3. Final offer and package design

4. Factory construction and design



After-Sales Service



1. Technical support abroad

2. Maintenance of foreign equipment

3. English speaking engineers can provide technical support
