Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D

Product Details:

Place of Origin: Shanghai
Brand Name: Gofun
Certification: CE, ISO certificate
Model Number: GFM-APL

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: International standard package for shipping
Delivery Time: 45~90 days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 100 sets per year
Get Best Price Contact Now

Detail Information

Power(w): 15kw Warranty: 12months
After-sales Service: Overseas Service Center Available Material: Stainless Steel 304 Or 316
Function: Processing Usage: Apple Grading Machine
Advantage: High Quantity And Efficiency Name: Apple Waxing Machine/fruit Processing Line
High Light:

100T/D Apple Juice Processing Line

,

Sus316L Apple Juice Processing Line

,

Food Grade Apple Processing Line

Product Description

Sus304/316L 10-100T/D Apple Juice Processing Line High Quality Service



Product description of the apple processing line




In addition to supplying apple processing equipment to the plant, Gofun can also provide one-stop solutions from A to Z, such as:

  • Technical consultation
  • Customized proposal design
  • Equipment manufacturing
  • Installation test run and on-site training
  • 1 year after sales warranty
  • Lifelong service
  • Package design and purchase



Main parameters of the apple production line

Product name: One-stop solution for apple processing line
Fresh fruit inlet capacity: 500kg per hour ~ 25 tons per hour, customized
Raw material: Fresh apple
End product: apple pulp, apple puree, apple juice, apple jam, dry apple and etc.
Final product Brix: 10%~12%
Final package: Aseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
The main material for machines: Food grade SUS304 or SUS316
Warranty: 12 months after commissioning
Operator needed: About 10~12 persons
Voltage: 380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Advantages: Energy-saving, High efficiency, Water-saving, Stable performance




Flowchart of apple paste/ sauce or ketchup processing





Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 0



Final products & Package types for the apple project



Shanghai Gofun machinery company offers all kinds of apple processing line.



Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 1



Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 2



Key process of the apple processing line



Now Shanghai Gofun machinery company will introduce the information of apple pulp puree or apple paste concentrate processing line to show it works.



1. Discharge platform

A fresh apple arrives, usually by a big truck, and it would be very difficult to unload it by one person. Therefore, we designed the unloading platform to unload the fresh apples from the truck using water cannons, while the fresh apples are transported to the processing line with water. And the unloading platform has a function to pre-wash fresh apples before processing.



2. Elevator

This machine is used to delivery fresh apple from outside the building to inside.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 3

3. Washing

Before remove the peels and seeds of fresh apple, need to washing fresh fruit carefully. For washing we can use bubble washing machine and brush & spray washing machine together.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 4

4. Sorting

After washing, the surface of apple is clean, we can check the situation of all the fruit by human eye, and sort out the bad apples by human.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 5

5. Crushing

GFM-FC series crusher has most advanced working principle, higher accuracy of manufacture and best crushing functions.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 6

6. Preheating

The pre-heater is used to heat the product after crusher, the temperature is adjustable, normally from 45℃ to 85℃. This processing step, would help to higher the juice rate for next step, and also can protect the color and taste of the final product.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 7

7. Belt type juice extractor

The belt press manufactured by Guofeng Company for reference to foreign advanced technology is a high-efficiency and large-scale press, which can increase the juice output during the processing of fruit juice or vegetable juice.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 8



9. Sterilizing

For apple pulp puree/ apple paste, we use tube in tube type sterilizer for sterilizing. The sterilizing temperature and holding time is adjustable. With this machine we will heat the product to a very high temperature around 115℃ holding for 30s and then cooling to ambient temperature immediately.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 9

10. Aseptic Filling

Aseptic filling machines are used in conjunction with tube-in-tube sterilizers. This is a closed loop.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 10

11. Storage or go blending

The finished product can be stored or used as the raw material to make the apple sauce or ketchup.

Food Grade Sus304 / 316L Apple Juice Processing Line 10 - 100T/D 11
