Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H
  • Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H
  • Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H
  • Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H
  • Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H
  • Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H
  • Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H
  • Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H

Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H

Place of Origin Shanghai
Brand Name Gofun
Certification CE, ISO certificate
Model Number GFM-MPL
Product Details
Warranty:
1 Year
Voltage:
220V/380V
Power(w):
7.5kw
Condition:
New
Type:
Turnkey Processing Line
Capacity:
1T/D To 1500T/D
Name:
Mango Juice/pulp Processing Machines
Weight:
As The Capacity
Application:
Mango,Fruit Or Vegetable
Certification:
CE ISO
Material:
SUS304
Product Name:
Mango Juice Processing/Making Machine/Production Line
Highlight:

1t/H Mango Juice Processing Machine

,

Automatic Mango Juice Processing Machine

,

20t/H Mango Juice Processing Machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiable
Packaging Details
International standard package for shipping
Delivery Time
45~90 days
Payment Terms
T/T, Western Union, L/C
Supply Ability
100 sets per year
Product Description

Mango Juice Processing Machine Production Line 1 T/H-20t/H



Product description of the mango processing line



The mango processing line is designed to efficiently transform fresh mangoes into various final products, such as mango pulp, mango puree, mango concentrated sauce, mango sauce, mango juice, and mango beverages. The entire process, starting from raw mangoes to the finished products, is carried out under aseptic conditions to ensure optimal quality and preservation. The products are then packaged in barrels to maintain their freshness and quality.



To achieve this, the mango processing line consists of several essential components. These include a fresh mango receiving system, washing system, sorting system, stone removal system, preheating system, cellulose preparation and purification system, filtration system, concentration system, sterilization system, and aseptic filling system. Each stage plays a crucial role in producing high-quality mango products.



The mango sauce, which is packaged in aseptic bags within drums, can undergo further processing to create a wide variety of mango-based products. These include mango juice beverages, sauces, and various packaging options such as filling bags, metal cans, aluminum cans, PP containers, PET bottles, glass bottles, and triangular packaging formats. This range of packaging options allows for flexibility in meeting customer preferences and market demands.



Gofun not only provides tomato processing equipment for factories, but also can provide one-stop solutions from A to Z, such as:

  • Technical consulting
  • customized program design
  • Equipment manufacturing
  • On-site installation, commissioning and training
  • 1 year after-sales service warranty
  • Lifetime service
  • package design and purchase

Main parameters of the mango production line

Product name: One-stop solution for mango processing line
Fresh fruit inlet capacity: 500kg per hour ~ 25 tons per hour, customized
Raw material: Fresh mango
End product: Mango pulp puree, Mango concentrate, Mango sauce, Mango juice, Mango beverage
Final product Brix: 14%~20%
Final package: Aseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
The main material for machines: Food grade SUS304 or SUS316
Warranty: 12 months after commissioning
Operator needed: About 10~12 persons
Voltage: 380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Advantages: Energy-saving, High efficiency, Water-saving, Stable performance




Flowchart of tomato paste/ sauce or ketchup processing



FRESH MANGO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTINING ⇒ PREHEATING ⇒ PULPING & REFINING ⇒ CENTRIFUGE ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING



Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H 0



The main machines of processing line



Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H 1

Sorting and Washing Machine

Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H 2

Destoning

Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H 3

Sterilizing

Tube in Tube Type Sterilizer is specially used for processing concentrated paste and other high viscosity materials. The equipment adopts a four layer casing structure, uses heated water as heating medium to instantly heat and sterilize the material, and then uses cooling water or ice water to quickly cool the sterilized material. The heat exchange medium flows in the innermost two layers and the outermost layer of the tube, so as to ensure the maximum heat exchange area and efficiency, the internal temperature of the material is uniform, and the material is fully sterilized.



Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H 4

Aseptic filling

This Filling Machine is used for filling the fruit juice, paste, puree, pulp and other liquid into the Aseptic Bags for storage. The natural fruit juice or pulp can be kept in the aseptic bags for more than one year under constant temperature, which could save the cost for cold chain storage and transportation.
The Aseptic Filling Machine can be connected with the serialization system directly, the product will be filled into the Aseptic Bags after fully sterilized by the sterilizer. The Aseptic Bags are aluminum compound multi-layer bags. It can cut off from sunlight and oxygen affection to guarantee the the high quality of the products. The Aseptic Filling System could also be designed as BIB (automatic Aseptic bag in box ) filling system to fulfil different application.



Final products & Package types for the mango project



Shanghai Gofun machinery company offers all kinds of mango processing line.



The raw materials are fresh mango, mango sauce, etc., and the finished products are mango sauce, mango sauce, mango juice, mango powder, diced mango, dried mango, etc.

Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H 5

The final packaging is aseptic bags, metal cans, pouches, standing pouches, PP containers, glass bottles, PET bottles, gable tops, etc.



Automatic Mango Juice Processing Machine Production Line 1t/H - 20t/H 6

Features



  1. Affordable Price and High Cost-Effectiveness: Our tomato processing line offers the most competitive pricing in the market without compromising on quality. We provide excellent value for your investment compared to our peers.
  2. Superior Quality and Reliability: Our equipment adheres to international standards and certifications, including ISO certification, guaranteeing top-notch quality and reliability. You can trust in the durability and performance of our tomato processing line.
  3. Versatility and Flexibility: Our production line is designed to accommodate various mango product specifications, packaging requirements, and processing methods. It offers adaptability and flexibility to meet your specific needs and production demands.
  4. Energy Efficiency: We prioritize energy efficiency in our equipment selection. By choosing energy-efficient components and technologies, our tomato processing line helps reduce energy costs and minimizes dependence on energy resources, contributing to a more sustainable operation.
  5. Local Adaptability: We understand the importance of equipment that can adapt to the local environment and working conditions. Our team takes into account factors such as climate conditions, power supply availability, equipment size, and installation requirements to ensure the suitability of our tomato processing line to your specific region.

Company Profile



Shanghai Gofun Machinery Co., Ltd. is a technology-based private joint-stock enterprise. The company specializes in designing and manufacturing the whole line of fruit and vegetable processing and packaging equipment, and is committed to providing one-stop solutions for fruit and vegetable processing projects. From process design and optimization, plant layout, to equipment design, manufacturing, installation and after-sales, are all tailor-made for customers. The company has focus on fruit and vegetable industry nearly 15 years, more than 100 domestic and foreign engineering cases, and have accumulated rich engineering experience in processing technology and equipment of fruit juice, paste, dried fruit and beverage. We absorb the advantages of European design concept and automation control technology, and constantly improve in the production and manufacturing, so that the fruit and vegetable processing technology has been comprehensively improved.

The company's main products include: fruit and vegetable pretreatment machine, juice extracting machine and pulping machine, evaporation system, sterilization system, aseptic filling system etc. The company can undertake all kinds of complete sets of fruit and vegetable processing line (processing capacity 10-1500 tons / day), including: tomato, mango, apple, pear, citrus, goji, peach, apricot, strawberry, pineapple, coconut, pumpkin, celery and other fruits and vegetables.



What can we do?



1. We can provide customized services for mango processing production lines
2. Dedicated engineers design solutions for you
3. Provide successful cases in multiple regions in Africa
4. Provide factory inspection services
