Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
  • Industrial Tomato Paste Processing Line for Fruit Factory
Industrial Tomato Paste Processing Line for Fruit Factory

Industrial Tomato Paste Processing Line for Fruit Factory

Place of Origin Shanghai
Brand Name Gofun
Certification CE, ISO certificate
Model Number GFM-MPL
Product Details
Warranty:
12 Months
Certification:
CE/ ISO9001
Voltage:
220/380/440V, According To Customers
Power(w):
7.5kw
Type:
Turnkey Processing Line From A To Z
Material:
SUS304/ SUS316
Capacity:
1 T/h-20 T/h
Product Name:
Mango Dried Processing Machine
After-sales Service:
Oversea Technical Support
Application:
Mango
Condition:
New
Weight:
Customized
Highlight:

Industrial tomato paste processing line

,

Tomato processing line for factory

,

Fruit factory tomato paste equipment

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiable
Packaging Details
International standard package for shipping
Delivery Time
45~90 days
Payment Terms
T/T,Western Union,L/C
Supply Ability
100 sets per year
Product Description

Industrial Tomato Paste Processing Line for Fruit Factory

This full automatic tomato paste production line is a complete industrial processing system for commercial food factories to produce high quality standard tomato paste. The whole workflow from fresh tomato feeding to final aseptic filling runs automatically under PLC control, which greatly reduces labor cost and keeps every batch product quality consistent.
The line supports hourly capacity from 500kg/h to 5000kg/h, and can be customized to higher capacity according to your annual tomato processing volume. It can produce different Brix levels of tomato paste, which is suitable for industrial bulk raw material supply, catering packaging and export standard tomato paste products.
All core processing units are made of high quality food grade 304 stainless steel. The double stage refining system effectively separates tomato skin and seeds, making the final tomato paste fine and uniform without coarse fiber residue. The aseptic filling section can pack final paste into 200L aseptic drum, tin can or small retail pouch.
We provide full turnkey service including project layout design, equipment manufacturing, on-site installation guidance and operator training. This tomato paste production line has been widely recognized by global tomato processing clients for its stable performance and reasonable investment cost.

Technical Specifications
Product Name One-stop solution for mango processing line
Fresh Fruit Inlet Capacity 500kg per hour ~ 25 tons per hour, customized
Raw Material Fresh mango
End Products Mango pulp puree, Mango concentrate, Mango sauce, Mango juice, Mango beverage
Final Product Brix 14%~20%
Final Package Options Aseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
Machine Material Food grade SUS304 or SUS316
Warranty 12 months after commissioning
Operator Requirement About 10~12 persons
Voltage 380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Advantages Energy-saving, High efficiency, Water-saving, Stable performance
Processing Flowchart
FRESH MANGO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTINING ⇒ PREHEATING ⇒ PULPING & REFINING ⇒ CENTRIFUGE ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING
Complete mango processing line overview showing all equipment components
Final Products & Packaging Options
Our processing line utilizes fresh mango and mango paste as raw materials to produce various final products including mango paste, mango sauce, mango juice, mango powder, diced mango, and dried mango.
Various mango products produced by our processing line including puree, juice, and dried mango
Available packaging formats include aseptic bags, metal cans, sachets, stand-up pouches, PP containers, glass bottles, PET bottles, and gable top cartons.
Different packaging options for mango products showing various container types
Key Features
  • Full-process Integration: Comprehensive mango processing from pretreatment to bottling of finished products within a single integrated system
  • Safety Assurance: Built with 304/316 stainless steel and FDA/CE certification for ensuring food safety standards
  • Smart and Productive: Precise parameter control via PLC with adjustable capacity ranging from 500kg/h to 10t/h
  • Energy-efficient and Eco-friendly: Low-power configuration to minimize operational expenses
  • Versatile Functionality: Capable of processing mango pulp, various juices, and vegetable purees
  • Complete Support: Tailored design, installation, commissioning, technical training, and post-sales assistance services
Detailed Process Steps
1. Discharge Platform
Specialized drainage platform with water guns simplifies raw mango unloading from trucks while providing pre-washing capabilities to enhance production line efficiency.
2. Elevator
This machine transports fresh mango from outside the building to inside the processing facility.
Mango elevator machine for transporting fresh fruit into processing facility
3. Washing
Thorough washing of fresh fruits prior to crushing using bubble washers and brush & spray washers. Optional ultrasonic and ozone cleaning methods available for enhanced cleaning efficacy.
Mango washing process showing fruit cleaning equipment
4. Sorting
Visual inspection by staff after washing to identify defects, ensuring only high-quality fruits proceed through the production line.
Mango sorting process with quality control inspection
5. Destoning
Mango remover operates at 1470 r/min, effectively crushing fresh mango to ensure thorough cleaning of core and skin, maximizing pulp yield and production efficiency.
Mango destoning machine for removing pits and skins
6. Preheating
Adjustable temperature pre-heater (45℃ to 85℃) increases juice yield for subsequent processing while protecting final product color and taste.
Mango preheating equipment for temperature treatment
7. Pulper and Refiner
Operating at 1470 r/min, this machine generates centrifugal force to pass product through screens for refinement. Suitable for various fruits including passion fruit, tomatoes, peaches, apricots, mangoes, and apples.
Pulper and refiner machine for mango processing
8. Horizontal Spiral Centrifugal
Reduces solids and impurities to ensure mango pulp puree is free from contaminants and black spots.
Horizontal spiral centrifugal machine for impurity removal
9. Sterilizing
Tube-in-tube type sterilizer with adjustable temperature and retention time for different product requirements. Programmable control system ensures precise automation.
Sterilization equipment for mango processing ensuring product safety
10. Aseptic Filling
Operates with tube-in-tube sterilizer in closed cycle system. Vapor-protected filling cavity maintains sterility throughout the packaging process.
Aseptic filling machine for mango products
11. Storage or Blending
Final product can be stored as-is or used as raw material for producing mango sauce or other products.
Final mango product storage options showing bulk containers
Animation demonstrating mango processing line operation
Animation showing mango packaging process
